Aluminum alloy fixed installation flood baffle

Brand Name : SPEK

Model Number : SSL-DB1

Place of Origin : CHINA JIANGSU

MOQ : 1 square meter

Price : 1 US dollar

Payment Terms : L/C, T/T

Supply Ability : 10000Meter/Meters per Month

Delivery Time : 1--15 days

Packaging Details : wooden box

Name : Aluminum flood baffle

Material : 6063-T5 Aluminum Alloy Material

Type : Manger

Application : Hones ,Offices,Schools,Hospitals

Function : Flood Proofing

Certificate : ISO9001

Contact Now



Aluminum Alloy Profiles Flood Barrier



description of  products



    This product is made of 6063 T5 aluminum alloy material , extrusion of aluminum alloy profiles, the thickness of  aluminum profiles 2.3mm. The surface electrophoresis oxidation treatment ,each baffle plate and baffle place is equipped with a bearing head  combined,and EPDM waterproof   strip. EPFM water proof strips with a height of more than 4cm and a height of more than 2cm are arranged at the bottom of the water baffle and the waterfproof effeft is more than 99%.





Aluminum alloy fixed installation flood baffle







                        Aluminum alloy fixed installation flood baffle







       single chip size : (height*thickness*wall thickness) 215MM*50MM*2.2MM



        Yield strength  ≥ 110MPA



       Strength  of extension: ≥160MPA (MPA)



       Border material :   6063--T5 Aluminum alloy extrusion molding,the surface using sand blasting,         ,electrophorsis, oxidation treatment.



        Border size: (Length*width*thickness) 103MM*78MM*6MM



          Sealing material :   Baffle joints are provided with card slots and EPDM waterproof sealing strips. The baffke plate that is in direct contact with the ground is provide with 25 thicker waterproof rubber strips . Both ends of the baffle plate are provided with sealing covers,which are integrated mold forming to prevent dirt from entering the hollow parts.



ground material : 304 stainless steel



specification(height*width*wall thickness):  60MM*50MM*1.5MM



                                                       measurement mode





Aluminum alloy fixed installation flood baffleAluminum alloy fixed installation flood baffle



     Aluminum alloy fixed installation flood baffleAluminum alloy fixed installation flood baffle





Aluminum alloy fixed installation flood baffle



Aluminum alloy fixed installation flood baffleAluminum alloy fixed installation flood baffle



Aluminum alloy fixed installation flood baffle



Aluminum alloy fixed installation flood baffle

Steps for removing flood baffle



Aluminum alloy fixed installation flood baffle



Aluminum alloy fixed installation flood baffle



Aluminum alloy fixed installation flood baffle



Practical case

    Aluminum alloy fixed installation flood baffle



Aluminum alloy fixed installation flood baffle



Aluminum alloy fixed installation flood baffle

Aluminum alloy fixed installation flood baffle



Patent security



Aluminum alloy fixed installation flood baffle





Aluminum alloy fixed installation flood baffle       Aluminum alloy fixed installation flood baffle       Aluminum alloy fixed installation flood baffle
